Multiple-blade wood pallet block cutting machine

Multiple-blade wood pallet block cutting machine

1. Optional automatic feeding and stacking.
2. Need parts to change block height
3. 2 workers for easy operation.
4. Siemens motor.
  • pallet block cutting machine
  • wood block cutting machine
  • Multiple-blade wood pallet block cutting machine

Wood pallet block cutting machine (multiple-blade model), suitable for processing shavings pallet blocks, solid woods, multi-layer woods. The machine is stable, efficient, safe, and simple and so on. And it is also dominant in wood pallet processing equipment.

This wood pallet  block cutting machine is with simple operation, no error, no fault, and easy to operate, Any workers can be directly on the job, after the factory 3-5 hours of training. The dust of the machine is less, when cutting the pallet blocks, the dust-collecting effect is much better than the pallet cutting machine.

Chain plate / chain feeding, and navigation sheet discharge, is suitable for processing shorter wood. The feeding chain penetrates the machine frame, and the whole chain feeding can cut the shorter wooden side and the sawing is smoother. This device can make it more economical than other types of multi-blade saws.

Wood block cutting machine features

  1. High production efficiency, with cutting 5 m3 in one hour.
  2. The bullet-proof chain is installed at the inlet to prevent the wood chips from rebounding. And the slope is installed at the discharge port, and the discharge is smooth, preventing the wood from flying out.
  3. There is a safety shield on the top of pallet block cutting machine (multiple-blade model), so it is safer to place the wood.
  4. The whole process is automatic feeding, the upper and lower shaft structure, multi-piece sawing, continuous discharging, so the efficiency is increased by 5-6 times, and the sawing road is thinner than other machines.
  5. Excellent quality motor for long service life.
  6. The multi-blade sawing process is stable, the sawing precision is high, the surface is smooth and flat, no need to re-process, and reducing wood waste.
  7. The power-enhanced feeding conveyor is strong and powerful, reducing the labor intensity of workers and making the sawing logs more stable.
  8. Powerful cylinder drives feeding, and low failure rate. High quality imported transmission chain is with durability.

Technical Parameter

Model PMC-7000
Overall dimension 1950*1450*1300 mm
Precision 0.5 mm
Max cut width 200 mm
Max cut thickness 120 mm
Max cut length 1250 mm
Feeding speed 7 s/cut
Main motor power 30 kW
Voltage 380 V, 50 Hz, 3P
Net weight 1100 kg
Blade size/quantity 355*3.2*60T*30/14pcs
Motor brand Siemens
Electrical parts Schneider
Bearings brand NSK from Japan
